acA2040-25gm - Basler ace
The Basler acA2040-25gm GigE camera with the CMOSIS CMV4000 CMOS sensor delivers 25 frames per second at 4 MP resolution.
General Information |
||
|---|---|---|
| Order Number | 105715 | |
| Product Line | ace Classic | |
| Price | For pricing, please use the request cart to get a quote. | |
| Shipment | For information about shipping please use the request cart. | |
Sensor |
||
|---|---|---|
| Sensor Vendor | CMOSIS | |
| Sensor | CMV4000 | |
| Shutter | Global Shutter | |
| Max. Image Circle | 1" | |
| Sensor Type | CMOS | |
| Sensor Size | 11.3 mm x 11.3 mm | |
| Resolution (HxV) | 2048 px x 2048 px | |
| Resolution | 4 MP | |
| Pixel Size (H x V) | 5.5 µm x 5.5 µm | |
| Frame Rate | 25 fps | |
| Mono/Color | Mono | |
EMVA Data |
||
|---|---|---|
| EMVA Quantum Efficiency (typical) | 62.1 % | |
| Dark Noise (typical) | 13.8 e¯ | |
| Saturation Capacity (typical) | 11.9 ke¯ | |
| Dynamic Range (typical) | 58.7 dB | |
| Signal-to-Noise Ratio (typical) | 40.8 dB | |
Camera Data |
||
|---|---|---|
| Interface | GigE | |
| Synchronization |
|
|
| Exposure Control |
|
|
| Digital Input | 1 | |
| Digital Output | 1 | |
| Power Supply |
|
|
| Power Requirements (typical) | 2.6 W | |
| Power Consumption PoE | 3.1 W | |
Housing |
||
|---|---|---|
| Housing Type | Box | |
| Housing Size (L x W x H) | 42 mm x 29 mm x 29 mm | |
| Lens Mount |
|
|
| Operating Temperature | 0 - 50°C | |
| Weight (typical) | 90g | |
Conformity |
||
|---|---|---|
| Conformity |
|
|
